Classeq C500 Underbench Dishwasher

Regular price

Classeq Underbench Dishwasher C500

The C500 is compact, simple to use, simple to clean and robust enough to withstand the pressures of any busy kitchen or bar.

Commissioned as a glass or dishwasher on install. As a glasswasher the 500 x 500mm basket can hold 25 pint-sized glasses and wash up to 1,000 glasses per hour. As a dishwasher the basket can hold 18 dinner plates and wash up to 540 plates per hour.

The C500 comes complete with a drain pump, rinse booster pump and detergent and rinse aid pumps with a double skinned door and cabinet to reduce noise and limit heat loss.

Inside, the C500 has new click in, click out wash arms, a new double filtration system, and new moulded wash tank and basket rails, all enhancing wash results and making the machine simple to clean. Reduced rinse water consumption and detergent usage.

Key Features:

  • Colour coded display
  • Reduced rinse water consumption
  • Energy saving standby mode
  • Drain pump, rinse booster pump, detergent and rinse aid pumps
  • Double skinned door and cabinet to reduce noise and limit heat loss
  • Hygiene and service reminders
  • Deep clean mode and refresh cycle
  • Optional audible alarm
  • Bluetooth connectivity
  • Three power options: 15A, 30A Single Phase and 15A three phase

Specifications:

  • Dimensions: H 850mm x W 600mm x D 600mm
  • Clear entry height: 352 mm
  • Depth - Door open: 989 mm
  • Rack/Basket Size: 500 x 500 mm
  • Racks per hour - Dish: 30
  • Racks per hour - Glass: 40
  • Wash tank capacity: 15L
  • Wash temperature: 60˚C
  • Programme duration - Dish: 2, 3 & 5 min. cycles
  • Programme duration - Glass: 1.5 & 2 min. cycles
  • Electrical connection: 15 Amp, (1 Phase) 220-240V/ 1N ~ / 50Hz
  • Total connected load: 2.5kW
  • Minimum incoming water temperature: 4°C
  • Maximum incoming water temperature: 55°C
  • Pumped drain height (from machine base): 600 mm
  • Drain size: 40mm diam.

For full specifications, click here
